CBX Turbo Bike

msproul@jove.rutgers.edu


Engine and orginal bike built by Michael O'driscoll of Canada



Click here for more pictures

Specifications
  • Engine
    • Honda CBX motor, 6 cylinder, bored out to 1129 cc, turbo charged (69 cu in)
    • RC Engineering pistons (no longer available)
    • ATP Turbo Rajay F40 (American Turbo-Pak, no longer in business)
    • HRC electric boost controller/progressive boost control system
    • S&S Super E carb
    • Carrillo rods
    • Falicon Supercrank
    • FBG undercut transmission
    • Dyna S Ignition
    • Racing valve springs
    • Lightly cleaned up head
    • Stock cams
    • M.R.E Lockup clutch made by Murdoch Racing Enterprises
    • Offset sprocket by D & G Chassis
  • Frame
    • Athanas Racing Chassis custom frame
    • RC Comp bearing support, custom bearing holder
    • RC Comp 10x15 rear wheel
    • PMFR front end
    • Bodywork - Beasley Fiberglass
HISTORY
Sep 2, 2003 Started working on air shifter hoses
Aug 30, 2003 Started installing Autometer gauges
Aug 30, 2003 Re-routed oil return from Turbo, now goes into clutch cover (as per suggestion from Mr Turbo)
Aug 30, 2003 Installed MRE Lockup clutch
Aug 30, 2003 Frame back from painter
Aug 25, 2003 Received gauges from Autometer
Aug 25, 2003 Delivered frame to painter
Aug 18, 2003 Offset bearing plate modified to fit
Aug 12, 2003 Received 15 tooth offset sprocket from D&G Chassis
Jul 19, 2003 Back to Athanas for wheelie bar and misc finishing touches on frame
Mar 1, 2003 Installed engine, working on fitting things together
Feb 14, 2003 Picked up custom frame from Athanas Racing Chassis
Oct 1, 2002 Engine runs
Sep 8, 2002 Purchased bike from Michael O'driscoll
TO DO LIST FOR DRAG BIKE
Finish lock up clutch
Get clutch handle, front brake, throttle
Install Air shifter controls
Re-weld waste gate
Puchase and install fuel pump
Transfer boost controller from sport bike
Transfer water injection from sport bike
Install battery
Make wiring harness
Paint bodywork
TO DO LIST FOR SPORT BIKE
Replace right brake handle assembly with spare, return to Mike
Finish air shifter
Modify seat for larger person (me)
Check or replace all wiring
Replace throttle cables
Install air can for air shifter
Install new engine
